NVIDIA RTX4090 D 24GB GPU Dual Wide Turbo Founders Edition Graphics Card

PCIE Graphics Card RTX3060 12GB 192BIT GDDR6
Version Number ：BP3060B-6A56A  Draft Date： 2025-06

1. Component name: PCIE graphics card RTX3060 12GB 192BIT GDDR6
2. Function description: It can meet the output of ordinary graphics card function
3. Special device requirements:
4. Main chip: GA106-302-A1 Pipeline: 3584 Power consumption: 170W
5. Video memory: GDDR6 512*32 6PCS
6. Output interface: 1xHDMI 2.1+3x DisplayPort 1.4a
7. Cooling method: 4pin turbo fan
8. GPU features: Support NVIDIA® GeForce Experience, NVIDIA®Ansel, NVIDIA®
9. Highlights, NVIDIA® G-SYNC™
   Compatible with game-ready driver, real-time ray tracing, Microsoft® DirectX® 12(12_2) API, Vulkan
10. Application program interface: OpenGL4. 6,.support SLI.
11. Resolution: HDMI™ 2.1 Maximum resolution: 7680 x4320 x24bpp at 60Hz
    DisplayPort 1.4a Maximum pixel frequency: 2120M/pixel per second, maximum bandwidth: 32.4Gbps
    Example of maximum resolution of CVT-RB timing
12. Electrical performance specifications: Chip frequency: 1320MHZ BOOST: 1777MHZ
13. Video memory frequency: 1875MHZ 16 Gbps
14. Capacity: 12GB
15. Software specifications: Operating system requirements: Windows7
16. Windows10 Windows11
17. Fan test conditions: High temperature experiment: 50±5 degrees high temperature aging for 8 hours, should be able to operate normally.
18. Ambient temperature 45 degrees: PASS
19. Is the GPU temperature controlled: With temperature control
20. Is the noise normal: Normal
